That's what makes the Style special:
The LMC Style is an affordable caravan for beginners, families and couples and has won an award in the “Caravan of the Year 2024” competition. The name Style says it all: for all those who want to bring a breath of fresh air to their camping vacation, the LMC Style offers a modern interior design with a furniture décor in soft sage green. The LMC Style combines functionality and style and is ideal as a family caravan.
Drop-down bed in a caravan? Only available in the Style series!
The LMC Style is available in 8 different layouts, including a lift model with a drop-down bed. The Style Lift 500 K impresses not only with the drop-down bed but also with a generous standing height of 2.08 meters and a children's bed at the front of the caravan. The Style 400 F is a small caravan under 6 meters with a folding bed above the seating area - ideal for couples or with the LMC pop-up roof for camping with children. The innovative folding bed solution won the European Innovation Award in 2023. Convince yourself of the modern interior design in the LMC Style: the light oak furniture, the sage green color scheme, the concrete-look floor and the matt black accents make the Style a real eye-catcher.
Find out more about the LMC Style and Style Lift!
a) All prices are recommended retail prices in EUR, based on the German retail prices. Prices in other countries may differ due to currency, country specific VAT, country specification, transportation charges or import duties. Your local dealer informes you about the applicable prices, taxes and duties for your country.
*The technically permissible total mass is a value specified by the manufacturer, which the vehicle must not exceed, even when loaded. It therefore has an influence on the permissible number of seats, options for selecting special equipment and remaining payload options.
Detailed information on weights and vehicle configuration can be found in our technical data, legal information section and in the configurator.
Description | Value |
---|---|
Pricea) | 19900 |
Total length | 583 |
Exterior length | 463 |
Interior length | 399 |
Total width | 233 |
Interior roof height max. | 198 |
Total height | 261 |
Weight in drivable condition (with standard equipment)* | 1032 (980 - 1084)* |
Manufacturer-specified dimensions for optional equipment* | 146 |
Maximum permissible total weight* | 1300 |
Floor, wall, roof thickness | 40 / 30 / 30 |
Awning size | 864 |
Berths standard / max. | 2 / 4 (○) |
Rear | 190 x 149 |
Bunk bed | 234 x 133 (○) |
Chassis |
---|
Premium-Chassis |
Stability support |
Diagonal swing axle |
Steel rim incl. wheel hub cap with summer tires |
Anti-sway coupling |
Breakdown kit |
Wheel shock absorbers |
Cabine exterior |
---|
hinged window incl. blackout blind and insect screen |
Service flap 750 x 300 mm rear passenger side |
Opening window bow 900 x 520 mm incl. blackout blind and insect screen |
Third breaking light |
Sidewall hammer finish sheet |
Roof hood clear glass 400 x 400 mm (sleeping) incl. blackout blind and insect screen |
Automotive tail light |
Bottle crate lid with gas strut |
Roof hood 280 x 280 mm (bathroom) incl. blackout blind and insect screen |
Roof hood clear glass 400 x 400 mm (living area) incl. blackout blind and insect screen |
Cabine interior |
---|
Cold foam mattress 110mm in single and double beds incl. slatted frame |
Furniture construction and ventilated upholstery and mattresses for optimum air circulation |
Storage cupboard |
Coat hooks |
Pad Style Dunit |
Vanity unit with door |
Mirror in the bathroom |
Kitchen |
---|
Three-burner hob with integrated sink split and glass cover |
Drawer with cutlery application |
Drawers with self retraction and softclose |
Compressor refrigerator 131.5 l with ice compartment |
Water supply |
---|
Central waste water drainage |
Cassette toilet |
Modern bathroom sink |
Freshwater tank with filler pipe, 44 ltr. |
Multimedia |
---|
LMC Home ready |
Gas/Electricity supply |
---|
LED interior lighting |
400 W transformer |
CEE external connection for 230 V with RCD and charger |
Reading lights |
Smoke alarm |
Power input sidewall |
Gas bottle box (for 2 x 11 kg) |
Gas regulator 30 mbar with gas hose (with country-specific adapter) |
Heating |
---|
Gas heating 3 kW |
Long Life Technology |
---|
Underbody with high-performance XPS foam and GRP |
Roof and front / rear section in GRP |
12-years-tightness-warranty |
Package elements |
---|
Wheel shock absorbers |
Anti-sway coupling |
Freshwater tank with filler pipe, 44 ltr. |
Wasserversorgung |
---|
Freshwater tank with filler pipe, 44 ltr. |
Andere Außenausstattungen |
---|
Service flap 750 x 300 mm rear passenger side |
Fahrzeugausstattung |
---|
Wheel shock absorbers |
Anti-sway coupling |
Fenster & Türen |
---|
Opening window bow 900 x 520 mm incl. blackout blind and insect screen |
Chassis |
---|
Stability supports incl. plate feet |
Shiny black alloy wheels with summer tires |
Anti-skid system |
Mover single axle (only in connection with autarchy package) |
Support wheel with support load indicator |
17" shiny black alloy wheel with summer tires |
Tow bar cover |
Payload upgrade |
---|
Maximum chassis weight 1.500 kg / 1.500 kg Chassis |
Maximum chassis weight 1.700 kg / 1.700 kg Chassis |
Cabine exterior |
---|
Entrance door with window incl. blackout blind, one-piece incl. waste garbage can |
Preparation for air conditioning incl. roof reinforcement |
Spare wheel holder in bottle holder |
Opening window side wall 700 x 520 mm incl. blackout blind and insect screen |
Hinged bathroom window (frosted glass) incl. blackout blind and insect screen |
Pop-up roof |
Winterisolation for pop-up roof |
Roof air conditioning (cooling and heating) |
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
Cabine interior |
---|
Shower curtain |
Wooden shower inlay |
Premium mattress 130mm incl. slatted base frame |
Insect screen door in superstructure door |
Pad Style Fenit |
Water supply |
---|
Holding tank 25 ltr. with wheels |
Therme for hot water supply 5 l (hot water mixer tap included) |
Display for freshwater tank |
Level sensor for fresh and waste water tank |
Multimedia |
---|
TV preparation (1x12V socket, 2x antenna cable SAT/TV) |
LMC Home |
Gas/Electricity supply |
---|
LED ambience lightning |
LED awning lighting |
DuoControl with crash sensor |
Gas level sensor |
12 V main switch |
Battery 95 AH AGM |
Gas detector |
Exterior socket 230 V / 12 V / TV and gas |
2x USB socket for power rail |
Heating |
---|
Electrical floor heating 230 V |
Electric auxiliary heater 2 kW |
Air circulation system for gas heating |
Package elements |
---|
Gas level sensor |
Wooden shower inlay |
Shower basin |
LED ambience lightning |
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
LED awning lighting |
Level sensor for fresh and waste water tank |
LMC Home |
Shower curtain |
Shower fitting |
Tire pressure sensors |
Support wheel with support load sensor |
12 V main switch |
Voltage indicator for battery |
Accu |
Battery 95 AH AGM |
Exterior socket 230 V / 12 V / TV and gas |
Air circulation system for gas heating |
12 V ventilation system |
DuoControl with crash sensor |
Packages |
---|
LMC Home sensor package |
Style package |
Shower package |
Autarchy package hot-air heating |
Wasserversorgung |
---|
Shower basin |
Shower curtain |
Shower fitting |
Holding tank 25 ltr. with wheels |
Display for freshwater tank |
Pop-up roof |
---|
Pop-up roof |
Winterisolation for pop-up roof |
Andere Außenausstattungen |
---|
Spare wheel holder in bottle holder |
Roof air conditioning (cooling and heating) |
Preparation for air conditioning incl. roof reinforcement |
Elektro- und Gasversorgung |
---|
Voltage indicator for battery |
Accu |
Battery 95 AH AGM |
Gas detector |
Exterior socket 230 V / 12 V / TV and gas |
2x USB socket for power rail |
12 V main switch |
DuoControl with crash sensor |
Fahrzeugausstattung |
---|
Stability supports incl. plate feet |
Mover single axle (only in connection with autarchy package) |
Anti-skid system |
Support wheel with support load indicator |
Fenster & Türen |
---|
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
Entrance door with window incl. blackout blind, one-piece incl. waste garbage can |
Opening window side wall 700 x 520 mm incl. blackout blind and insect screen |
Hinged bathroom window (frosted glass) incl. blackout blind and insect screen |
Heating |
---|
Electrical floor heating 230 V |
Therme for hot water supply 5 l (hot water mixer tap included) |
Electric auxiliary heater 2 kW |
12 V ventilation system |
Air circulation system for gas heating |
Weitere Innenausstattungen |
---|
Premium mattress 130mm incl. slatted base frame |
LED ambience lightning |
Insect screen door in superstructure door |
Multimedia |
---|
TV preparation (1x12V socket, 2x antenna cable SAT/TV) |
Payload upgrade |
---|
Maximum chassis weight 1.700 kg / 1.700 kg Chassis |
Maximum chassis weight 1.500 kg / 1.500 kg Chassis |
a) All prices are recommended retail prices in EUR, based on the German retail prices. Prices in other countries may differ due to currency, country specific VAT, country specification, transportation charges or import duties. Your local dealer informes you about the applicable prices, taxes and duties for your country.
*The technically permissible total mass is a value specified by the manufacturer, which the vehicle must not exceed, even when loaded. It therefore has an influence on the permissible number of seats, options for selecting special equipment and remaining payload options.
Detailed information on weights and vehicle configuration can be found in our technical data, legal information section and in the configurator.
Description | Value |
---|---|
Pricea) | 22600 |
Total length | 682 |
Exterior length | 560 |
Interior length | 493 |
Total width | 233 |
Interior roof height max. | 198 |
Total height | 261 |
Weight in drivable condition (with standard equipment)* | 1125 (1069 - 1181)* |
Manufacturer-specified dimensions for optional equipment* | 106 |
Maximum permissible total weight* | 1360 |
Floor, wall, roof thickness | 40 / 30 / 30 |
Awning size | 962 |
Berths standard / max. | 4 / 6 (○) |
Front | 210 x 144 - 110 |
Rear | 212 x 132 - 148 |
Bunk bed | 234 x 133 (○) |
Chassis |
---|
Premium-Chassis |
Stability support |
Diagonal swing axle |
Steel rim incl. wheel hub cap with summer tires |
Anti-sway coupling |
Breakdown kit |
Wheel shock absorbers |
Cabine exterior |
---|
hinged window incl. blackout blind and insect screen |
Rear hinged window 1,450 x 520 mm incl. blackout blind and insect screen |
Service flap 1,000 x 420 mm front passenger side |
Third breaking light |
Sidewall hammer finish sheet |
Roof hood clear glass 400 x 400 mm (sleeping) incl. blackout blind and insect screen |
Automotive tail light |
Bottle crate lid with gas strut |
Roof hood 280 x 280 mm (bathroom) incl. blackout blind and insect screen |
Roof hood clear glass 400 x 400 mm (living area) incl. blackout blind and insect screen |
Cabine interior |
---|
Gas pressure regulators on the slatted frames of the fixed beds |
Cold foam mattress 110mm in single and double beds incl. slatted frame |
Furniture construction and ventilated upholstery and mattresses for optimum air circulation |
Storage cupboard |
Coat hooks |
Pad Style Dunit |
Vanity unit with door |
Mirror in the bathroom |
Kitchen |
---|
Three-burner hob with integrated sink split and glass cover |
Drawer with cutlery application |
Drawers with self retraction and softclose |
Compressor refrigerator 131.5 l with ice compartment |
Water supply |
---|
Central waste water drainage |
Cassette toilet |
Modern bathroom sink |
Freshwater tank with filler pipe, 44 ltr. |
Multimedia |
---|
LMC Home ready |
Gas/Electricity supply |
---|
LED interior lighting |
400 W transformer |
CEE external connection for 230 V with RCD and charger |
Reading lights |
Smoke alarm |
Power input sidewall |
Gas bottle box (for 2 x 11 kg) |
Gas regulator 30 mbar with gas hose (with country-specific adapter) |
Heating |
---|
Gas heating 3 kW |
Long Life Technology |
---|
Underbody with high-performance XPS foam and GRP |
Roof and front / rear section in GRP |
12-years-tightness-warranty |
Package elements |
---|
Wheel shock absorbers |
Anti-sway coupling |
Freshwater tank with filler pipe, 44 ltr. |
Wasserversorgung |
---|
Freshwater tank with filler pipe, 44 ltr. |
Andere Außenausstattungen |
---|
Service flap 1,000 x 420 mm front passenger side |
Fahrzeugausstattung |
---|
Wheel shock absorbers |
Anti-sway coupling |
Fenster & Türen |
---|
Rear hinged window 1,450 x 520 mm incl. blackout blind and insect screen |
Chassis |
---|
Stability supports incl. plate feet |
Shiny black alloy wheels with summer tires |
Anti-skid system |
Mover single axle (only in connection with autarchy package) |
Support wheel with support load indicator |
17" shiny black alloy wheel with summer tires |
Tow bar cover |
Payload upgrade |
---|
Maximum chassis weight 1.500 kg / 1.500 kg Chassis |
Maximum chassis weight 1.700 kg / 1.700 kg Chassis |
Cabine exterior |
---|
Entrance door with window incl. blackout blind, one-piece incl. waste garbage can |
Preparation for air conditioning incl. roof reinforcement |
Spare wheel holder in bottle holder |
Hinged bathroom window (frosted glass) incl. blackout blind and insect screen |
Opening window bow 900 x 520 mm incl. blackout blind and insect screen |
Sliding window (kitchen) incl. blackout blind and insect screen |
Pop-up roof |
Winterisolation for pop-up roof |
Roof air conditioning (cooling and heating) |
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
Cabine interior |
---|
Shower curtain |
Wooden shower inlay |
Premium mattress 130mm incl. slatted base frame |
Insect screen door in superstructure door |
Pad Style Fenit |
Water supply |
---|
Holding tank 25 ltr. with wheels |
Therme for hot water supply 5 l (hot water mixer tap included) |
Display for freshwater tank |
Level sensor for fresh and waste water tank |
Multimedia |
---|
TV preparation (1x12V socket, 2x antenna cable SAT/TV) |
LMC Home |
Gas/Electricity supply |
---|
LED ambience lightning |
LED awning lighting |
DuoControl with crash sensor |
Gas level sensor |
12 V main switch |
Battery 95 AH AGM |
Gas detector |
Exterior socket 230 V / 12 V / TV and gas |
2x USB socket for power rail |
Heating |
---|
Electrical floor heating 230 V |
Electric auxiliary heater 2 kW |
Air circulation system for gas heating |
Package elements |
---|
Gas level sensor |
Wooden shower inlay |
Shower basin |
LED ambience lightning |
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
LED awning lighting |
Level sensor for fresh and waste water tank |
LMC Home |
Shower curtain |
Shower fitting |
Tire pressure sensors |
Support wheel with support load sensor |
12 V main switch |
Voltage indicator for battery |
Accu |
Battery 95 AH AGM |
Exterior socket 230 V / 12 V / TV and gas |
Air circulation system for gas heating |
12 V ventilation system |
DuoControl with crash sensor |
Packages |
---|
LMC Home sensor package |
Style package |
Shower package |
Autarchy package hot-air heating |
Wasserversorgung |
---|
Shower basin |
Shower curtain |
Shower fitting |
Holding tank 25 ltr. with wheels |
Display for freshwater tank |
Pop-up roof |
---|
Pop-up roof |
Winterisolation for pop-up roof |
Andere Außenausstattungen |
---|
Spare wheel holder in bottle holder |
Roof air conditioning (cooling and heating) |
Preparation for air conditioning incl. roof reinforcement |
Elektro- und Gasversorgung |
---|
Voltage indicator for battery |
Accu |
Battery 95 AH AGM |
Gas detector |
Exterior socket 230 V / 12 V / TV and gas |
2x USB socket for power rail |
12 V main switch |
DuoControl with crash sensor |
Fahrzeugausstattung |
---|
Stability supports incl. plate feet |
Mover single axle (only in connection with autarchy package) |
Anti-skid system |
Support wheel with support load indicator |
Fenster & Türen |
---|
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
Entrance door with window incl. blackout blind, one-piece incl. waste garbage can |
Opening window bow 900 x 520 mm incl. blackout blind and insect screen |
Hinged bathroom window (frosted glass) incl. blackout blind and insect screen |
Sliding window (kitchen) incl. blackout blind and insect screen |
Heating |
---|
Electrical floor heating 230 V |
Therme for hot water supply 5 l (hot water mixer tap included) |
Electric auxiliary heater 2 kW |
12 V ventilation system |
Air circulation system for gas heating |
Weitere Innenausstattungen |
---|
Premium mattress 130mm incl. slatted base frame |
LED ambience lightning |
Insect screen door in superstructure door |
Multimedia |
---|
TV preparation (1x12V socket, 2x antenna cable SAT/TV) |
Payload upgrade |
---|
Maximum chassis weight 1.700 kg / 1.700 kg Chassis |
Maximum chassis weight 1.500 kg / 1.500 kg Chassis |
a) All prices are recommended retail prices in EUR, based on the German retail prices. Prices in other countries may differ due to currency, country specific VAT, country specification, transportation charges or import duties. Your local dealer informes you about the applicable prices, taxes and duties for your country.
*The technically permissible total mass is a value specified by the manufacturer, which the vehicle must not exceed, even when loaded. It therefore has an influence on the permissible number of seats, options for selecting special equipment and remaining payload options.
Detailed information on weights and vehicle configuration can be found in our technical data, legal information section and in the configurator.
Description | Value |
---|---|
Pricea) | 22700 |
Total length | 735 |
Exterior length | 613 |
Interior length | 546 |
Total width | 233 |
Interior roof height max. | 198 |
Total height | 261 |
Weight in drivable condition (with standard equipment)* | 1171 (1112 - 1230)* |
Manufacturer-specified dimensions for optional equipment* | 48 |
Maximum permissible total weight* | 1360 |
Floor, wall, roof thickness | 40 / 30 / 30 |
Awning size | 1015 |
Berths standard / max. | 4 / 6 (○) |
Front | 200 x 146 |
Rear | 212 x 102 - 132 |
Bunk bed | 234 x 133 (○) |
Chassis |
---|
Premium-Chassis |
Stability support |
Diagonal swing axle |
Steel rim incl. wheel hub cap with summer tires |
Anti-sway coupling |
Breakdown kit |
Wheel shock absorbers |
Cabine exterior |
---|
hinged window incl. blackout blind and insect screen |
Rear hinged window 1,450 x 520 mm incl. blackout blind and insect screen |
Service flap 750 x 300 mm front passenger side |
Third breaking light |
Sidewall hammer finish sheet |
Roof hood clear glass 400 x 400 mm (sleeping) incl. blackout blind and insect screen |
Automotive tail light |
Bottle crate lid with gas strut |
Roof hood 280 x 280 mm (bathroom) incl. blackout blind and insect screen |
Roof hood clear glass 400 x 400 mm (living area) incl. blackout blind and insect screen |
Cabine interior |
---|
Gas pressure regulators on the slatted frames of the fixed beds |
Cold foam mattress 110mm in single and double beds incl. slatted frame |
Furniture construction and ventilated upholstery and mattresses for optimum air circulation |
Storage cupboard |
Coat hooks |
Pad Style Dunit |
Vanity unit with door |
Mirror in the bathroom |
Kitchen |
---|
Three-burner hob with integrated sink split and glass cover |
Drawer with cutlery application |
Drawers with self retraction and softclose |
Compressor refrigerator 131.5 l with ice compartment |
Water supply |
---|
Central waste water drainage |
Cassette toilet |
Modern bathroom sink |
Freshwater tank with filler pipe, 44 ltr. |
Multimedia |
---|
LMC Home ready |
Gas/Electricity supply |
---|
LED interior lighting |
400 W transformer |
CEE external connection for 230 V with RCD and charger |
Reading lights |
Smoke alarm |
Power input sidewall |
Gas bottle box (for 2 x 11 kg) |
Gas regulator 30 mbar with gas hose (with country-specific adapter) |
Heating |
---|
Gas heating 3 kW |
Long Life Technology |
---|
Underbody with high-performance XPS foam and GRP |
Roof and front / rear section in GRP |
12-years-tightness-warranty |
Package elements |
---|
Wheel shock absorbers |
Anti-sway coupling |
Freshwater tank with filler pipe, 44 ltr. |
Wasserversorgung |
---|
Freshwater tank with filler pipe, 44 ltr. |
Andere Außenausstattungen |
---|
Service flap 750 x 300 mm front passenger side |
Fahrzeugausstattung |
---|
Wheel shock absorbers |
Anti-sway coupling |
Fenster & Türen |
---|
Rear hinged window 1,450 x 520 mm incl. blackout blind and insect screen |
Chassis |
---|
Stability supports incl. plate feet |
Shiny black alloy wheels with summer tires |
Anti-skid system |
Mover single axle (only in connection with autarchy package) |
Support wheel with support load indicator |
17" shiny black alloy wheel with summer tires |
Tow bar cover |
Payload upgrade |
---|
Maximum chassis weight 1.600 kg / 1.600 kg Chassis |
Maximum chassis weight 1.800 kg / 1.800 kg Chassis |
Cabine exterior |
---|
Entrance door with window incl. blackout blind, one-piece incl. waste garbage can |
Preparation for air conditioning incl. roof reinforcement |
Spare wheel holder in bottle holder |
Service flap 750 x 300 mm front driver's side |
Service flap 750 x 300 mm rear passenger side |
Hinged bathroom window (frosted glass) incl. blackout blind and insect screen |
Opening window bow 900 x 520 mm incl. blackout blind and insect screen |
Sliding window (kitchen) incl. blackout blind and insect screen |
Pop-up roof |
Winterisolation for pop-up roof |
Roof air conditioning (cooling and heating) |
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
Cabine interior |
---|
Shower curtain |
Wooden shower inlay |
Premium mattress 130mm incl. slatted base frame |
Insect screen door in superstructure door |
Pad Style Fenit |
Water supply |
---|
Holding tank 25 ltr. with wheels |
Therme for hot water supply 5 l (hot water mixer tap included) |
Display for freshwater tank |
Level sensor for fresh and waste water tank |
Multimedia |
---|
TV preparation (1x12V socket, 2x antenna cable SAT/TV) |
LMC Home |
Gas/Electricity supply |
---|
LED ambience lightning |
LED awning lighting |
DuoControl with crash sensor |
Gas level sensor |
12 V main switch |
Battery 95 AH AGM |
Gas detector |
Exterior socket 230 V / 12 V / TV and gas |
2x USB socket for power rail |
Heating |
---|
Electrical floor heating 230 V |
Electric auxiliary heater 2 kW |
Air circulation system for gas heating |
Package elements |
---|
Gas level sensor |
Wooden shower inlay |
Shower basin |
LED ambience lightning |
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
LED awning lighting |
Level sensor for fresh and waste water tank |
LMC Home |
Shower curtain |
Shower fitting |
Tire pressure sensors |
Support wheel with support load sensor |
12 V main switch |
Voltage indicator for battery |
Accu |
Battery 95 AH AGM |
Exterior socket 230 V / 12 V / TV and gas |
Air circulation system for gas heating |
12 V ventilation system |
DuoControl with crash sensor |
Packages |
---|
LMC Home sensor package |
Style package |
Shower package |
Autarchy package hot-air heating |
Wasserversorgung |
---|
Shower basin |
Shower curtain |
Shower fitting |
Holding tank 25 ltr. with wheels |
Display for freshwater tank |
Pop-up roof |
---|
Pop-up roof |
Winterisolation for pop-up roof |
Andere Außenausstattungen |
---|
Spare wheel holder in bottle holder |
Roof air conditioning (cooling and heating) |
Service flap 750 x 300 mm rear passenger side |
Service flap 750 x 300 mm front driver's side |
Preparation for air conditioning incl. roof reinforcement |
Elektro- und Gasversorgung |
---|
Voltage indicator for battery |
Accu |
Battery 95 AH AGM |
Gas detector |
Exterior socket 230 V / 12 V / TV and gas |
2x USB socket for power rail |
12 V main switch |
DuoControl with crash sensor |
Fahrzeugausstattung |
---|
Stability supports incl. plate feet |
Mover single axle (only in connection with autarchy package) |
Anti-skid system |
Support wheel with support load indicator |
Fenster & Türen |
---|
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
Entrance door with window incl. blackout blind, one-piece incl. waste garbage can |
Opening window bow 900 x 520 mm incl. blackout blind and insect screen |
Hinged bathroom window (frosted glass) incl. blackout blind and insect screen |
Sliding window (kitchen) incl. blackout blind and insect screen |
Heating |
---|
Electrical floor heating 230 V |
Therme for hot water supply 5 l (hot water mixer tap included) |
Electric auxiliary heater 2 kW |
12 V ventilation system |
Air circulation system for gas heating |
Weitere Innenausstattungen |
---|
Premium mattress 130mm incl. slatted base frame |
LED ambience lightning |
Insect screen door in superstructure door |
Multimedia |
---|
TV preparation (1x12V socket, 2x antenna cable SAT/TV) |
Payload upgrade |
---|
Maximum chassis weight 1.600 kg / 1.600 kg Chassis |
Maximum chassis weight 1.800 kg / 1.800 kg Chassis |
a) All prices are recommended retail prices in EUR, based on the German retail prices. Prices in other countries may differ due to currency, country specific VAT, country specification, transportation charges or import duties. Your local dealer informes you about the applicable prices, taxes and duties for your country.
*The technically permissible total mass is a value specified by the manufacturer, which the vehicle must not exceed, even when loaded. It therefore has an influence on the permissible number of seats, options for selecting special equipment and remaining payload options.
Detailed information on weights and vehicle configuration can be found in our technical data, legal information section and in the configurator.
Description | Value |
---|---|
Total length | 735 |
Exterior length | 613 |
Interior length | 546 |
Total width | 233 |
Interior roof height max. | 198 |
Total height | 261 |
Weight in drivable condition (with standard equipment)* | 1171 (1112 - 1230)* |
Manufacturer-specified dimensions for optional equipment* | 48 |
Maximum permissible total weight* | 1360 |
Floor, wall, roof thickness | 40 / 30 / 30 |
Awning size | 1015 |
Berths standard / max. | 4 / 6 (○) |
Front | 200 x 146 |
Rear | 212 x 102 - 132 |
Bunk bed | 234 x 133 (○) |
Chassis |
---|
Premium-Chassis |
Diagonal swing axle |
Anti-sway coupling |
Breakdown kit |
Wheel shock absorbers |
Cabine exterior |
---|
hinged window incl. blackout blind and insect screen |
Rear hinged window 1,450 x 520 mm incl. blackout blind and insect screen |
Service flap 750 x 300 mm front passenger side |
Third breaking light |
Sidewall hammer finish sheet |
Roof hood clear glass 400 x 400 mm (sleeping) incl. blackout blind and insect screen |
Automotive tail light |
Bottle crate lid with gas strut |
Roof hood 280 x 280 mm (bathroom) incl. blackout blind and insect screen |
Roof hood clear glass 400 x 400 mm (living area) incl. blackout blind and insect screen |
Cabine interior |
---|
Gas pressure regulators on the slatted frames of the fixed beds |
Cold foam mattress 110mm in single and double beds incl. slatted frame |
Furniture construction and ventilated upholstery and mattresses for optimum air circulation |
Storage cupboard |
Coat hooks |
Vanity unit with door |
Mirror in the bathroom |
Kitchen |
---|
Three-burner hob with integrated sink split and glass cover |
Drawer with cutlery application |
Drawers with self retraction and softclose |
Compressor refrigerator 131.5 l with ice compartment |
Water supply |
---|
Central waste water drainage |
Cassette toilet |
Modern bathroom sink |
Freshwater tank with filler pipe, 44 ltr. |
Multimedia |
---|
LMC Home ready |
Gas/Electricity supply |
---|
LED interior lighting |
400 W transformer |
CEE external connection for 230 V with RCD and charger |
Reading lights |
Smoke alarm |
Power input sidewall |
Gas bottle box (for 2 x 11 kg) |
Gas regulator 30 mbar with gas hose (with country-specific adapter) |
Heating |
---|
Gas heating 3 kW |
Long Life Technology |
---|
Underbody with high-performance XPS foam and GRP |
Roof and front / rear section in GRP |
12-years-tightness-warranty |
Package elements |
---|
Wheel shock absorbers |
Anti-sway coupling |
Freshwater tank with filler pipe, 44 ltr. |
Style 70 years package |
Packages |
---|
Style 70 years package |
Wasserversorgung |
---|
Freshwater tank with filler pipe, 44 ltr. |
Andere Außenausstattungen |
---|
Service flap 750 x 300 mm front passenger side |
Fahrzeugausstattung |
---|
Wheel shock absorbers |
Anti-sway coupling |
Fenster & Türen |
---|
Rear hinged window 1,450 x 520 mm incl. blackout blind and insect screen |
Chassis |
---|
Mover single axle (only in connection with autarchy package) |
anti-skid system |
Cabine exterior |
---|
Service flap 750 x 300 mm front driver's side |
Service flap 750 x 300 mm rear passenger side |
Hinged bathroom window (frosted glass) incl. blackout blind and insect screen |
Opening window bow 900 x 520 mm incl. blackout blind and insect screen |
Sliding window (kitchen) incl. blackout blind and insect screen |
Pop-up roof |
Winterisolation for pop-up roof |
Roof air conditioning (cooling and heating) |
Cabine interior |
---|
Shower curtain |
Wooden shower inlay |
Premium mattress 130mm incl. slatted base frame |
3-seater bunk bed (load capacity 80 kg), each with its own window |
Water supply |
---|
Level sensor for fresh and waste water tank |
Multimedia |
---|
LMC Home |
Gas/Electricity supply |
---|
DuoControl with crash sensor |
Gas level sensor |
12 V main switch |
Battery 95 AH AGM |
Gas detector |
Exterior socket 230 V / 12 V / TV and gas |
Heating |
---|
Electrical floor heating 230 V |
Electric auxiliary heater 2 kW |
Package elements |
---|
Gas level sensor |
Wooden shower inlay |
Shower basin |
Level sensor for fresh and waste water tank |
LMC Home |
Shower curtain |
Shower fitting |
Tire pressure sensors |
Support wheel with support load sensor |
12 V main switch |
Voltage indicator for battery |
Accu |
Battery 95 AH AGM |
Exterior socket 230 V / 12 V / TV and gas |
12 V ventilation system |
DuoControl with crash sensor |
Packages |
---|
LMC Home sensor package |
Shower package |
Autarchy package hot-air heating |
Wasserversorgung |
---|
Shower basin |
Shower curtain |
Shower fitting |
Pop-up roof |
---|
Pop-up roof |
Winterisolation for pop-up roof |
Andere Außenausstattungen |
---|
Roof air conditioning (cooling and heating) |
Service flap 750 x 300 mm rear passenger side |
Service flap 750 x 300 mm front driver's side |
Elektro- und Gasversorgung |
---|
Voltage indicator for battery |
Accu |
Battery 95 AH AGM |
Gas detector |
Exterior socket 230 V / 12 V / TV and gas |
12 V main switch |
DuoControl with crash sensor |
Fahrzeugausstattung |
---|
Mover single axle (only in connection with autarchy package) |
anti-skid system |
Fenster & Türen |
---|
Opening window bow 900 x 520 mm incl. blackout blind and insect screen |
Hinged bathroom window (frosted glass) incl. blackout blind and insect screen |
Sliding window (kitchen) incl. blackout blind and insect screen |
Heating |
---|
Electrical floor heating 230 V |
Electric auxiliary heater 2 kW |
12 V ventilation system |
Weitere Innenausstattungen |
---|
Premium mattress 130mm incl. slatted base frame |
3-seater bunk bed (load capacity 80 kg), each with its own window |
Style 70 years package |
---|
70 years of special stickers |
Insect screen door in superstructure door |
Shiny black alloy wheels with summer tires |
Upholstery Dacit 70 year edition |
Stability supports incl. plate feet |
Illuminated edge strip |
Preparation for air conditioning incl. roof reinforcement |
Air circulation system for gas heating |
Therme for hot water supply 5 l (hot water mixer tap included) |
a) All prices are recommended retail prices in EUR, based on the German retail prices. Prices in other countries may differ due to currency, country specific VAT, country specification, transportation charges or import duties. Your local dealer informes you about the applicable prices, taxes and duties for your country.
*The technically permissible total mass is a value specified by the manufacturer, which the vehicle must not exceed, even when loaded. It therefore has an influence on the permissible number of seats, options for selecting special equipment and remaining payload options.
Detailed information on weights and vehicle configuration can be found in our technical data, legal information section and in the configurator.
Description | Value |
---|---|
Pricea) | 23100 |
Total length | 678 |
Exterior length | 553 |
Interior length | 490 |
Total width | 233 |
Interior roof height max. | 198 |
Total height | 261 |
Weight in drivable condition (with standard equipment)* | 1137 (1080 - 1194)* |
Manufacturer-specified dimensions for optional equipment* | 47 |
Maximum permissible total weight* | 1300 |
Floor, wall, roof thickness | 40 / 30 / 30 |
Awning size | 955 |
Berths standard / max. | 3 / 5 (○) |
Front | 185 - 210 x 83 - 83 |
Middle | 212 x 110 |
Bunk bed | 234 x 133 (○) |
Chassis |
---|
Premium-Chassis |
Stability support |
Diagonal swing axle |
Steel rim incl. wheel hub cap with summer tires |
Anti-sway coupling |
Breakdown kit |
Wheel shock absorbers |
Cabine exterior |
---|
hinged window incl. blackout blind and insect screen |
Rear hinged window 1,450 x 520 mm incl. blackout blind and insect screen |
Service flap 1,000 x 420 mm front passenger side |
Third breaking light |
Sidewall hammer finish sheet |
Roof hood clear glass 400 x 400 mm (sleeping) incl. blackout blind and insect screen |
Automotive tail light |
Bottle crate lid with gas strut |
Roof hood 280 x 280 mm (bathroom) incl. blackout blind and insect screen |
Roof hood clear glass 400 x 400 mm (living area) incl. blackout blind and insect screen |
Cabine interior |
---|
Gas pressure regulators on the slatted frames of the fixed beds |
Cold foam mattress 110mm in single and double beds incl. slatted frame |
Furniture construction and ventilated upholstery and mattresses for optimum air circulation |
Storage cupboard |
Coat hooks |
Conversion of single bed to double bed with extendable slats |
Pad Style Dunit |
Vanity unit with door |
Mirror in the bathroom |
Kitchen |
---|
Compressor refrigerator 83 l with ice compartment |
Three-burner hob with integrated sink split and glass cover |
Drawer with cutlery application |
Drawers with self retraction and softclose |
Water supply |
---|
Central waste water drainage |
Cassette toilet |
Modern bathroom sink |
Freshwater tank with filler pipe, 44 ltr. |
Multimedia |
---|
LMC Home ready |
Gas/Electricity supply |
---|
LED interior lighting |
400 W transformer |
CEE external connection for 230 V with RCD and charger |
Reading lights |
Smoke alarm |
Power input sidewall |
Gas bottle box (for 2 x 11 kg) |
Gas regulator 30 mbar with gas hose (with country-specific adapter) |
Heating |
---|
Gas heating 3 kW |
Long Life Technology |
---|
Underbody with high-performance XPS foam and GRP |
Roof and front / rear section in GRP |
12-years-tightness-warranty |
Package elements |
---|
Wheel shock absorbers |
Anti-sway coupling |
Freshwater tank with filler pipe, 44 ltr. |
Wasserversorgung |
---|
Freshwater tank with filler pipe, 44 ltr. |
Andere Außenausstattungen |
---|
Service flap 1,000 x 420 mm front passenger side |
Fahrzeugausstattung |
---|
Wheel shock absorbers |
Anti-sway coupling |
Fenster & Türen |
---|
Rear hinged window 1,450 x 520 mm incl. blackout blind and insect screen |
Weitere Innenausstattungen |
---|
Conversion of single bed to double bed with extendable slats |
Chassis |
---|
Stability supports incl. plate feet |
Shiny black alloy wheels with summer tires |
Anti-skid system |
Mover single axle (only in connection with autarchy package) |
Support wheel with support load indicator |
17" shiny black alloy wheel with summer tires |
Tow bar cover |
Payload upgrade |
---|
Maximum chassis weight 1.500 kg / 1.500 kg Chassis |
Maximum chassis weight 1.700 kg / 1.700 kg Chassis |
Cabine exterior |
---|
Entrance door with window incl. blackout blind, one-piece incl. waste garbage can |
Preparation for air conditioning incl. roof reinforcement |
Spare wheel holder in bottle holder |
Service flap 1,000 x 420 mm front driver's side |
Hinged bathroom window (frosted glass) incl. blackout blind and insect screen |
Opening window bow 1,589 x 580 mm incl. blackout blind and insect screen |
Sliding window (kitchen) incl. blackout blind and insect screen |
Pop-up roof |
Winterisolation for pop-up roof |
Roof air conditioning (cooling and heating) |
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
Cabine interior |
---|
Shower curtain |
Wooden shower inlay |
Premium mattress 130mm incl. slatted base frame |
Insect screen door in superstructure door |
Pad Style Fenit |
Water supply |
---|
Holding tank 25 ltr. with wheels |
Therme for hot water supply 5 l (hot water mixer tap included) |
Display for freshwater tank |
Level sensor for fresh and waste water tank |
Multimedia |
---|
TV preparation (1x12V socket, 2x antenna cable SAT/TV) |
LMC Home |
Gas/Electricity supply |
---|
LED ambience lightning |
LED awning lighting |
DuoControl with crash sensor |
Gas level sensor |
12 V main switch |
Battery 95 AH AGM |
Gas detector |
Exterior socket 230 V / 12 V / TV and gas |
2x USB socket for power rail |
Heating |
---|
Electrical floor heating 230 V |
Electric auxiliary heater 2 kW |
Air circulation system for gas heating |
Package elements |
---|
Gas level sensor |
Wooden shower inlay |
Shower basin |
LED ambience lightning |
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
LED awning lighting |
Level sensor for fresh and waste water tank |
LMC Home |
Shower curtain |
Shower fitting |
Tire pressure sensors |
Support wheel with support load sensor |
12 V main switch |
Voltage indicator for battery |
Accu |
Battery 95 AH AGM |
Exterior socket 230 V / 12 V / TV and gas |
Air circulation system for gas heating |
12 V ventilation system |
DuoControl with crash sensor |
Packages |
---|
LMC Home sensor package |
Style package |
Shower package |
Autarchy package hot-air heating |
Wasserversorgung |
---|
Shower basin |
Shower curtain |
Shower fitting |
Holding tank 25 ltr. with wheels |
Display for freshwater tank |
Pop-up roof |
---|
Pop-up roof |
Winterisolation for pop-up roof |
Andere Außenausstattungen |
---|
Spare wheel holder in bottle holder |
Roof air conditioning (cooling and heating) |
Service flap 1,000 x 420 mm front driver's side |
Preparation for air conditioning incl. roof reinforcement |
Elektro- und Gasversorgung |
---|
Voltage indicator for battery |
Accu |
Battery 95 AH AGM |
Gas detector |
Exterior socket 230 V / 12 V / TV and gas |
2x USB socket for power rail |
12 V main switch |
DuoControl with crash sensor |
Fahrzeugausstattung |
---|
Stability supports incl. plate feet |
Mover single axle (only in connection with autarchy package) |
Anti-skid system |
Support wheel with support load indicator |
Fenster & Türen |
---|
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
Entrance door with window incl. blackout blind, one-piece incl. waste garbage can |
Opening window bow 1,589 x 580 mm incl. blackout blind and insect screen |
Hinged bathroom window (frosted glass) incl. blackout blind and insect screen |
Sliding window (kitchen) incl. blackout blind and insect screen |
Heating |
---|
Electrical floor heating 230 V |
Therme for hot water supply 5 l (hot water mixer tap included) |
Electric auxiliary heater 2 kW |
12 V ventilation system |
Air circulation system for gas heating |
Weitere Innenausstattungen |
---|
Premium mattress 130mm incl. slatted base frame |
LED ambience lightning |
Insect screen door in superstructure door |
Multimedia |
---|
TV preparation (1x12V socket, 2x antenna cable SAT/TV) |
Payload upgrade |
---|
Maximum chassis weight 1.700 kg / 1.700 kg Chassis |
Maximum chassis weight 1.500 kg / 1.500 kg Chassis |
a) All prices are recommended retail prices in EUR, based on the German retail prices. Prices in other countries may differ due to currency, country specific VAT, country specification, transportation charges or import duties. Your local dealer informes you about the applicable prices, taxes and duties for your country.
*The technically permissible total mass is a value specified by the manufacturer, which the vehicle must not exceed, even when loaded. It therefore has an influence on the permissible number of seats, options for selecting special equipment and remaining payload options.
Detailed information on weights and vehicle configuration can be found in our technical data, legal information section and in the configurator.
Description | Value |
---|---|
Pricea) | 22900 |
Total length | 716 |
Exterior length | 588 |
Interior length | 521 |
Total width | 233 |
Interior roof height max. | 198 |
Total height | 261 |
Weight in drivable condition (with standard equipment)* | 1175 (1116 - 1234)* |
Manufacturer-specified dimensions for optional equipment* | 34 |
Maximum permissible total weight* | 1360 |
Floor, wall, roof thickness | 40 / 30 / 30 |
Awning size | 990 |
Berths standard / max. | 5 / 8 (○) |
Front | 208 x 135 |
Middle | 194 x 86 |
Rear | 212 - 208 x 81 - 74 |
Bunk bed | 234 x 133 (○) |
Chassis |
---|
Premium-Chassis |
Stability support |
Diagonal swing axle |
Steel rim incl. wheel hub cap with summer tires |
Anti-sway coupling |
Breakdown kit |
Wheel shock absorbers |
Cabine exterior |
---|
hinged window incl. blackout blind and insect screen |
Garage door |
Service flap 1,000 x 420 mm front passenger side |
Third breaking light |
Sidewall hammer finish sheet |
Roof hood clear glass 400 x 400 mm (sleeping) incl. blackout blind and insect screen |
Automotive tail light |
Rear hinged window 900 x 520 mm incl. blackout blind and insect screen |
Bottle crate lid with gas strut |
Roof hood 280 x 280 mm (bathroom) incl. blackout blind and insect screen |
Roof hood clear glass 280 x 280 mm (children's room) incl. blackout blind and insect screen |
Roof hood clear glass 400 x 400 mm (living area) incl. blackout blind and insect screen |
Cabine interior |
---|
Cold foam mattress 80mm in bunk beds incl. slatted frame |
Gas pressure regulators on the slatted frames of the fixed beds |
Cold foam mattress 110mm in single and double beds incl. slatted frame |
Bunk beds (load capacity 80 kg) each with its own window |
Furniture construction and ventilated upholstery and mattresses for optimum air circulation |
Storage cupboard |
Coat hooks |
Pad Style Dunit |
Vanity unit with door |
Mirror in the bathroom |
Kitchen |
---|
Three-burner hob with integrated sink split and glass cover |
Drawer with cutlery application |
Drawers with self retraction and softclose |
Compressor refrigerator 131.5 l with ice compartment |
Water supply |
---|
Central waste water drainage |
Cassette toilet |
Modern bathroom sink |
Freshwater tank with filler pipe, 44 ltr. |
Multimedia |
---|
LMC Home ready |
Gas/Electricity supply |
---|
LED interior lighting |
400 W transformer |
CEE external connection for 230 V with RCD and charger |
Reading lights |
Smoke alarm |
Power input sidewall |
Gas bottle box (for 2 x 11 kg) |
Gas regulator 30 mbar with gas hose (with country-specific adapter) |
Heating |
---|
Gas heating 3 kW |
Long Life Technology |
---|
Underbody with high-performance XPS foam and GRP |
Roof and front / rear section in GRP |
12-years-tightness-warranty |
Package elements |
---|
Wheel shock absorbers |
Anti-sway coupling |
Freshwater tank with filler pipe, 44 ltr. |
Wasserversorgung |
---|
Freshwater tank with filler pipe, 44 ltr. |
Andere Außenausstattungen |
---|
Service flap 1,000 x 420 mm front passenger side |
Fahrzeugausstattung |
---|
Wheel shock absorbers |
Anti-sway coupling |
Fenster & Türen |
---|
Garage door |
Chassis |
---|
Stability supports incl. plate feet |
Shiny black alloy wheels with summer tires |
Anti-skid system |
Mover single axle (only in connection with autarchy package) |
Support wheel with support load indicator |
17" shiny black alloy wheel with summer tires |
Tow bar cover |
Payload upgrade |
---|
Maximum chassis weight 1.700 kg / 1.700 kg Chassis |
Maximum chassis weight 1.500 kg / 1.500 kg Chassis |
Cabine exterior |
---|
Entrance door with window incl. blackout blind, one-piece incl. waste garbage can |
Preparation for air conditioning incl. roof reinforcement |
Spare wheel holder in bottle holder |
Hinged bathroom window (frosted glass) incl. blackout blind and insect screen |
Opening window bow 1,589 x 580 mm incl. blackout blind and insect screen |
Sliding window (kitchen) incl. blackout blind and insect screen |
Pop-up roof |
Winterisolation for pop-up roof |
Roof air conditioning (cooling and heating) |
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
Cabine interior |
---|
Shower curtain |
Wooden shower inlay |
Premium mattress 130mm incl. slatted base frame |
3-seater bunk bed (load capacity 80 kg), each with its own window |
Insect screen door in superstructure door |
Pad Style Fenit |
Water supply |
---|
Holding tank 25 ltr. with wheels |
Therme for hot water supply 5 l (hot water mixer tap included) |
Display for freshwater tank |
Level sensor for fresh and waste water tank |
Multimedia |
---|
TV preparation (1x12V socket, 2x antenna cable SAT/TV) |
LMC Home |
Gas/Electricity supply |
---|
LED ambience lightning |
LED awning lighting |
DuoControl with crash sensor |
Gas level sensor |
12 V main switch |
Battery 95 AH AGM |
Gas detector |
Exterior socket 230 V / 12 V / TV and gas |
2x USB socket for power rail |
Heating |
---|
Electrical floor heating 230 V |
Electric auxiliary heater 2 kW |
Air circulation system for gas heating |
Package elements |
---|
Gas level sensor |
Wooden shower inlay |
Shower basin |
LED ambience lightning |
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
LED awning lighting |
Level sensor for fresh and waste water tank |
LMC Home |
Shower curtain |
Shower fitting |
Tire pressure sensors |
Support wheel with support load sensor |
12 V main switch |
Voltage indicator for battery |
Accu |
Battery 95 AH AGM |
Exterior socket 230 V / 12 V / TV and gas |
Air circulation system for gas heating |
12 V ventilation system |
DuoControl with crash sensor |
Packages |
---|
LMC Home sensor package |
Style package |
Shower package |
Autarchy package hot-air heating |
Wasserversorgung |
---|
Shower basin |
Shower curtain |
Shower fitting |
Holding tank 25 ltr. with wheels |
Display for freshwater tank |
Pop-up roof |
---|
Pop-up roof |
Winterisolation for pop-up roof |
Andere Außenausstattungen |
---|
Spare wheel holder in bottle holder |
Roof air conditioning (cooling and heating) |
Preparation for air conditioning incl. roof reinforcement |
Elektro- und Gasversorgung |
---|
Voltage indicator for battery |
Accu |
Battery 95 AH AGM |
Gas detector |
Exterior socket 230 V / 12 V / TV and gas |
2x USB socket for power rail |
12 V main switch |
DuoControl with crash sensor |
Fahrzeugausstattung |
---|
Stability supports incl. plate feet |
Mover single axle (only in connection with autarchy package) |
Anti-skid system |
Support wheel with support load indicator |
Fenster & Türen |
---|
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
Entrance door with window incl. blackout blind, one-piece incl. waste garbage can |
Opening window bow 1,589 x 580 mm incl. blackout blind and insect screen |
Hinged bathroom window (frosted glass) incl. blackout blind and insect screen |
Sliding window (kitchen) incl. blackout blind and insect screen |
Heating |
---|
Electrical floor heating 230 V |
Therme for hot water supply 5 l (hot water mixer tap included) |
Electric auxiliary heater 2 kW |
12 V ventilation system |
Air circulation system for gas heating |
Weitere Innenausstattungen |
---|
Premium mattress 130mm incl. slatted base frame |
3-seater bunk bed (load capacity 80 kg), each with its own window |
LED ambience lightning |
Insect screen door in superstructure door |
Multimedia |
---|
TV preparation (1x12V socket, 2x antenna cable SAT/TV) |
Payload upgrade |
---|
Maximum chassis weight 1.700 kg / 1.700 kg Chassis |
Maximum chassis weight 1.500 kg / 1.500 kg Chassis |
a) All prices are recommended retail prices in EUR, based on the German retail prices. Prices in other countries may differ due to currency, country specific VAT, country specification, transportation charges or import duties. Your local dealer informes you about the applicable prices, taxes and duties for your country.
*The technically permissible total mass is a value specified by the manufacturer, which the vehicle must not exceed, even when loaded. It therefore has an influence on the permissible number of seats, options for selecting special equipment and remaining payload options.
Detailed information on weights and vehicle configuration can be found in our technical data, legal information section and in the configurator.
Description | Value |
---|---|
Total length | 716 |
Exterior length | 588 |
Interior length | 521 |
Total width | 233 |
Interior roof height max. | 198 |
Total height | 261 |
Weight in drivable condition (with standard equipment)* | 1175 (1116 - 1234)* |
Manufacturer-specified dimensions for optional equipment* | 34 |
Maximum permissible total weight* | 1360 |
Floor, wall, roof thickness | 40 / 30 / 30 |
Awning size | 990 |
Berths standard / max. | 5 / 8 (○) |
Front | 208 x 135 |
Middle | 194 x 86 |
Rear | 212 - 208 x 81 - 74 |
Bunk bed | 234 x 133 (○) |
Chassis |
---|
Premium-Chassis |
Diagonal swing axle |
Anti-sway coupling |
Breakdown kit |
Wheel shock absorbers |
Cabine exterior |
---|
hinged window incl. blackout blind and insect screen |
Service flap 1,000 x 420 mm front passenger side |
Third breaking light |
Sidewall hammer finish sheet |
Roof hood clear glass 400 x 400 mm (sleeping) incl. blackout blind and insect screen |
Automotive tail light |
Rear hinged window 900 x 520 mm incl. blackout blind and insect screen |
Bottle crate lid with gas strut |
Roof hood 280 x 280 mm (bathroom) incl. blackout blind and insect screen |
Roof hood clear glass 280 x 280 mm (children's room) incl. blackout blind and insect screen |
Roof hood clear glass 400 x 400 mm (living area) incl. blackout blind and insect screen |
Cabine interior |
---|
Cold foam mattress 80mm in bunk beds incl. slatted frame |
Gas pressure regulators on the slatted frames of the fixed beds |
Cold foam mattress 110mm in single and double beds incl. slatted frame |
Bunk beds (load capacity 80 kg) each with its own window |
Furniture construction and ventilated upholstery and mattresses for optimum air circulation |
Storage cupboard |
Coat hooks |
Vanity unit with door |
Mirror in the bathroom |
Kitchen |
---|
Three-burner hob with integrated sink split and glass cover |
Drawer with cutlery application |
Drawers with self retraction and softclose |
Compressor refrigerator 131.5 l with ice compartment |
Water supply |
---|
Central waste water drainage |
Cassette toilet |
Modern bathroom sink |
Freshwater tank with filler pipe, 44 ltr. |
Multimedia |
---|
LMC Home ready |
Gas/Electricity supply |
---|
LED interior lighting |
400 W transformer |
CEE external connection for 230 V with RCD and charger |
Reading lights |
Smoke alarm |
Power input sidewall |
Gas bottle box (for 2 x 11 kg) |
Gas regulator 30 mbar with gas hose (with country-specific adapter) |
Heating |
---|
Gas heating 3 kW |
Long Life Technology |
---|
Underbody with high-performance XPS foam and GRP |
Roof and front / rear section in GRP |
12-years-tightness-warranty |
Package elements |
---|
Wheel shock absorbers |
Anti-sway coupling |
Freshwater tank with filler pipe, 44 ltr. |
Style 70 years package |
Packages |
---|
Style 70 years package |
Wasserversorgung |
---|
Freshwater tank with filler pipe, 44 ltr. |
Andere Außenausstattungen |
---|
Service flap 1,000 x 420 mm front passenger side |
Fahrzeugausstattung |
---|
Wheel shock absorbers |
Anti-sway coupling |
Chassis |
---|
Mover single axle (only in connection with autarchy package) |
anti-skid system |
Cabine exterior |
---|
Hinged bathroom window (frosted glass) incl. blackout blind and insect screen |
Opening window bow 1,589 x 580 mm incl. blackout blind and insect screen |
Sliding window (kitchen) incl. blackout blind and insect screen |
Pop-up roof |
Winterisolation for pop-up roof |
Roof air conditioning (cooling and heating) |
Cabine interior |
---|
Shower curtain |
Wooden shower inlay |
Premium mattress 130mm incl. slatted base frame |
3-seater bunk bed (load capacity 80 kg), each with its own window |
Water supply |
---|
Level sensor for fresh and waste water tank |
Multimedia |
---|
LMC Home |
Gas/Electricity supply |
---|
DuoControl with crash sensor |
Gas level sensor |
12 V main switch |
Battery 95 AH AGM |
Gas detector |
Exterior socket 230 V / 12 V / TV and gas |
Heating |
---|
Electrical floor heating 230 V |
Electric auxiliary heater 2 kW |
Package elements |
---|
Gas level sensor |
Wooden shower inlay |
Shower basin |
Level sensor for fresh and waste water tank |
LMC Home |
Shower curtain |
Shower fitting |
Tire pressure sensors |
Support wheel with support load sensor |
12 V main switch |
Voltage indicator for battery |
Accu |
Battery 95 AH AGM |
Exterior socket 230 V / 12 V / TV and gas |
12 V ventilation system |
DuoControl with crash sensor |
Packages |
---|
LMC Home sensor package |
Shower package |
Autarchy package hot-air heating |
Wasserversorgung |
---|
Shower basin |
Shower curtain |
Shower fitting |
Pop-up roof |
---|
Pop-up roof |
Winterisolation for pop-up roof |
Andere Außenausstattungen |
---|
Roof air conditioning (cooling and heating) |
Elektro- und Gasversorgung |
---|
Voltage indicator for battery |
Accu |
Battery 95 AH AGM |
Gas detector |
Exterior socket 230 V / 12 V / TV and gas |
12 V main switch |
DuoControl with crash sensor |
Fahrzeugausstattung |
---|
Mover single axle (only in connection with autarchy package) |
anti-skid system |
Fenster & Türen |
---|
Opening window bow 1,589 x 580 mm incl. blackout blind and insect screen |
Hinged bathroom window (frosted glass) incl. blackout blind and insect screen |
Sliding window (kitchen) incl. blackout blind and insect screen |
Heating |
---|
Electrical floor heating 230 V |
Electric auxiliary heater 2 kW |
12 V ventilation system |
Weitere Innenausstattungen |
---|
Premium mattress 130mm incl. slatted base frame |
3-seater bunk bed (load capacity 80 kg), each with its own window |
Style 70 years package |
---|
70 years of special stickers |
Insect screen door in superstructure door |
Shiny black alloy wheels with summer tires |
Upholstery Dacit 70 year edition |
Stability supports incl. plate feet |
Illuminated edge strip |
Preparation for air conditioning incl. roof reinforcement |
Air circulation system for gas heating |
Therme for hot water supply 5 l (hot water mixer tap included) |
a) All prices are recommended retail prices in EUR, based on the German retail prices. Prices in other countries may differ due to currency, country specific VAT, country specification, transportation charges or import duties. Your local dealer informes you about the applicable prices, taxes and duties for your country.
*The technically permissible total mass is a value specified by the manufacturer, which the vehicle must not exceed, even when loaded. It therefore has an influence on the permissible number of seats, options for selecting special equipment and remaining payload options.
Detailed information on weights and vehicle configuration can be found in our technical data, legal information section and in the configurator.
Description | Value |
---|---|
Pricea) | 23800 |
Total length | 769 |
Exterior length | 635 |
Interior length | 568 |
Total width | 233 |
Interior roof height max. | 198 |
Total height | 261 |
Weight in drivable condition (with standard equipment)* | 1237 (1175 - 1299)* |
Manufacturer-specified dimensions for optional equipment* | 130 |
Maximum permissible total weight* | 1500 |
Floor, wall, roof thickness | 40 / 30 / 30 |
Awning size | 1040 |
Berths standard / max. | 4 / 6 (○) |
Front | 212 x 127 - 162 |
Rear | 206 - 215 x 88 - 88 |
Bunk bed | 234 x 133 (○) |
Chassis |
---|
Premium-Chassis |
Stability support |
Diagonal swing axle |
Steel rim incl. wheel hub cap with summer tires |
Anti-sway coupling |
Breakdown kit |
Wheel shock absorbers |
Cabine exterior |
---|
hinged window incl. blackout blind and insect screen |
Service flap 1,000 x 420 mm Rear passenger side |
Opening window bow 1,589 x 580 mm incl. blackout blind and insect screen |
Third breaking light |
Sidewall hammer finish sheet |
Roof hood clear glass 400 x 400 mm (sleeping) incl. blackout blind and insect screen |
Automotive tail light |
Bottle crate lid with gas strut |
Roof hood 280 x 280 mm (bathroom) incl. blackout blind and insect screen |
Roof hood clear glass 400 x 400 mm (living area) incl. blackout blind and insect screen |
Cabine interior |
---|
Gas pressure regulators on the slatted frames of the fixed beds |
Cold foam mattress 110mm in single and double beds incl. slatted frame |
Furniture construction and ventilated upholstery and mattresses for optimum air circulation |
Storage cupboard |
Coat hooks |
Conversion of single bed to double bed with extendable slats |
Pad Style Dunit |
Vanity unit with door |
Mirror in the bathroom |
Kitchen |
---|
Three-burner hob with integrated sink split and glass cover |
Drawer with cutlery application |
Drawers with self retraction and softclose |
Compressor refrigerator 131.5 l with ice compartment |
Water supply |
---|
Central waste water drainage |
Cassette toilet |
Modern bathroom sink |
Freshwater tank with filler pipe, 44 ltr. |
Multimedia |
---|
LMC Home ready |
Gas/Electricity supply |
---|
LED interior lighting |
400 W transformer |
CEE external connection for 230 V with RCD and charger |
Reading lights |
Smoke alarm |
Power input sidewall |
Gas bottle box (for 2 x 11 kg) |
Gas regulator 30 mbar with gas hose (with country-specific adapter) |
Heating |
---|
Gas heating 3 kW |
Long Life Technology |
---|
Underbody with high-performance XPS foam and GRP |
Roof and front / rear section in GRP |
12-years-tightness-warranty |
Package elements |
---|
Wheel shock absorbers |
Anti-sway coupling |
Freshwater tank with filler pipe, 44 ltr. |
Wasserversorgung |
---|
Freshwater tank with filler pipe, 44 ltr. |
Andere Außenausstattungen |
---|
Service flap 1,000 x 420 mm Rear passenger side |
Fahrzeugausstattung |
---|
Wheel shock absorbers |
Anti-sway coupling |
Fenster & Türen |
---|
Opening window bow 1,589 x 580 mm incl. blackout blind and insect screen |
Weitere Innenausstattungen |
---|
Conversion of single bed to double bed with extendable slats |
Chassis |
---|
Stability supports incl. plate feet |
Shiny black alloy wheels with summer tires |
Anti-skid system |
Mover single axle (only in connection with autarchy package) |
Support wheel with support load indicator |
17" shiny black alloy wheel with summer tires |
Tow bar cover |
Payload upgrade |
---|
Maximum chassis weight 1.800 kg / 1.800 kg Chassis |
Maximum chassis weight 1.600 kg / 1.600 kg Chassis |
Cabine exterior |
---|
Entrance door with window incl. blackout blind, one-piece incl. waste garbage can |
Preparation for air conditioning incl. roof reinforcement |
Rear hinged window 1,450 x 520 mm incl. blackout blind and insect screen |
Spare wheel holder in bottle holder |
Service flap 750 x 300 mm front passenger side |
Hinged bathroom window (frosted glass) incl. blackout blind and insect screen |
Sliding window (kitchen) incl. blackout blind and insect screen |
Pop-up roof |
Winterisolation for pop-up roof |
Roof air conditioning (cooling and heating) |
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
Cabine interior |
---|
Shower curtain |
Wooden shower inlay |
Premium mattress 130mm incl. slatted base frame |
Insect screen door in superstructure door |
Pad Style Fenit |
Water supply |
---|
Holding tank 25 ltr. with wheels |
Therme for hot water supply 5 l (hot water mixer tap included) |
Display for freshwater tank |
Level sensor for fresh and waste water tank |
Multimedia |
---|
TV preparation (1x12V socket, 2x antenna cable SAT/TV) |
LMC Home |
Gas/Electricity supply |
---|
LED ambience lightning |
LED awning lighting |
DuoControl with crash sensor |
Gas level sensor |
12 V main switch |
Battery 95 AH AGM |
Gas detector |
Exterior socket 230 V / 12 V / TV and gas |
2x USB socket for power rail |
Heating |
---|
Electrical floor heating 230 V |
Electric auxiliary heater 2 kW |
Air circulation system for gas heating |
Package elements |
---|
Gas level sensor |
Wooden shower inlay |
Shower basin |
LED ambience lightning |
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
LED awning lighting |
Level sensor for fresh and waste water tank |
LMC Home |
Shower curtain |
Shower fitting |
Tire pressure sensors |
Support wheel with support load sensor |
12 V main switch |
Voltage indicator for battery |
Accu |
Battery 95 AH AGM |
Exterior socket 230 V / 12 V / TV and gas |
Air circulation system for gas heating |
12 V ventilation system |
DuoControl with crash sensor |
Packages |
---|
LMC Home sensor package |
Style package |
Shower package |
Autarchy package hot-air heating |
Wasserversorgung |
---|
Shower basin |
Shower curtain |
Shower fitting |
Holding tank 25 ltr. with wheels |
Display for freshwater tank |
Pop-up roof |
---|
Pop-up roof |
Winterisolation for pop-up roof |
Andere Außenausstattungen |
---|
Spare wheel holder in bottle holder |
Roof air conditioning (cooling and heating) |
Service flap 750 x 300 mm front passenger side |
Preparation for air conditioning incl. roof reinforcement |
Elektro- und Gasversorgung |
---|
Voltage indicator for battery |
Accu |
Battery 95 AH AGM |
Gas detector |
Exterior socket 230 V / 12 V / TV and gas |
2x USB socket for power rail |
12 V main switch |
DuoControl with crash sensor |
Fahrzeugausstattung |
---|
Stability supports incl. plate feet |
Mover single axle (only in connection with autarchy package) |
Anti-skid system |
Support wheel with support load indicator |
Fenster & Türen |
---|
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
Entrance door with window incl. blackout blind, one-piece incl. waste garbage can |
Rear hinged window 1,450 x 520 mm incl. blackout blind and insect screen |
Hinged bathroom window (frosted glass) incl. blackout blind and insect screen |
Sliding window (kitchen) incl. blackout blind and insect screen |
Heating |
---|
Electrical floor heating 230 V |
Therme for hot water supply 5 l (hot water mixer tap included) |
Electric auxiliary heater 2 kW |
12 V ventilation system |
Air circulation system for gas heating |
Weitere Innenausstattungen |
---|
Premium mattress 130mm incl. slatted base frame |
LED ambience lightning |
Insect screen door in superstructure door |
Multimedia |
---|
TV preparation (1x12V socket, 2x antenna cable SAT/TV) |
Payload upgrade |
---|
Maximum chassis weight 1.600 kg / 1.600 kg Chassis |
Maximum chassis weight 1.800 kg / 1.800 kg Chassis |
a) All prices are recommended retail prices in EUR, based on the German retail prices. Prices in other countries may differ due to currency, country specific VAT, country specification, transportation charges or import duties. Your local dealer informes you about the applicable prices, taxes and duties for your country.
*The technically permissible total mass is a value specified by the manufacturer, which the vehicle must not exceed, even when loaded. It therefore has an influence on the permissible number of seats, options for selecting special equipment and remaining payload options.
Detailed information on weights and vehicle configuration can be found in our technical data, legal information section and in the configurator.
Description | Value |
---|---|
Pricea) | 26000 |
Total length | 805 |
Exterior length | 674 |
Interior length | 606 |
Total width | 252 |
Interior roof height max. | 198 |
Total height | 261 |
Weight in drivable condition (with standard equipment)* | 1377 (1308 - 1446)* |
Manufacturer-specified dimensions for optional equipment* | 57 |
Maximum permissible total weight* | 1600 |
Floor, wall, roof thickness | 40 / 30 / 30 |
Awning size | 1075 |
Berths standard / max. | 5 / 8 (○) |
Front | 205 x 169 |
Middle | 205 x 111 |
Rear | 197 - 200 x 78 - 82 |
Bunk bed | 234 x 133 (○) |
Chassis |
---|
Premium-Chassis |
Stability support |
Diagonal swing axle |
Steel rim incl. wheel hub cap with summer tires |
Anti-sway coupling |
Breakdown kit |
Wheel shock absorbers |
Cabine exterior |
---|
hinged window incl. blackout blind and insect screen |
Garage door |
Service flap 1,000 x 420 mm front driver's side |
Hinged bathroom window (frosted glass) incl. blackout blind and insect screen |
Third breaking light |
Rear hinged window 1,200 x 300 mm incl. blackout blind and insect screen |
Sidewall hammer finish sheet |
Roof hood clear glass 400 x 400 mm (sleeping) incl. blackout blind and insect screen |
Automotive tail light |
Bottle crate lid with gas strut |
Roof hood 280 x 280 mm (bathroom) incl. blackout blind and insect screen |
Roof hood clear glass 280 x 280 mm (children's room) incl. blackout blind and insect screen |
Roof hood clear glass 400 x 400 mm (living area) incl. blackout blind and insect screen |
Cabine interior |
---|
Cold foam mattress 80mm in bunk beds incl. slatted frame |
Gas pressure regulators on the slatted frames of the fixed beds |
Cold foam mattress 110mm in single and double beds incl. slatted frame |
Bunk beds (load capacity 80 kg) each with its own window |
Furniture construction and ventilated upholstery and mattresses for optimum air circulation |
Storage cupboard |
Coat hooks |
Pad Style Dunit |
Vanity unit with door |
Mirror in the bathroom |
Kitchen |
---|
Three-burner hob with integrated sink split and glass cover |
Drawer with cutlery application |
Drawers with self retraction and softclose |
Compressor refrigerator 131.5 l with ice compartment |
Water supply |
---|
Central waste water drainage |
Cassette toilet |
Modern bathroom sink |
Freshwater tank with filler pipe, 44 ltr. |
Multimedia |
---|
LMC Home ready |
Gas/Electricity supply |
---|
LED interior lighting |
400 W transformer |
CEE external connection for 230 V with RCD and charger |
Reading lights |
Smoke alarm |
Power input sidewall |
Gas bottle box (for 2 x 11 kg) |
Gas regulator 30 mbar with gas hose (with country-specific adapter) |
Heating |
---|
Gas heating 5 kW |
Long Life Technology |
---|
Underbody with high-performance XPS foam and GRP |
Roof and front / rear section in GRP |
12-years-tightness-warranty |
Package elements |
---|
Wheel shock absorbers |
Anti-sway coupling |
Freshwater tank with filler pipe, 44 ltr. |
Wasserversorgung |
---|
Freshwater tank with filler pipe, 44 ltr. |
Andere Außenausstattungen |
---|
Service flap 1,000 x 420 mm front driver's side |
Fahrzeugausstattung |
---|
Wheel shock absorbers |
Anti-sway coupling |
Fenster & Türen |
---|
Garage door |
Hinged bathroom window (frosted glass) incl. blackout blind and insect screen |
Chassis |
---|
Stability supports incl. plate feet |
Shiny black alloy wheels with summer tires |
Anti-skid system |
Mover single axle (only in connection with autarchy package) |
Support wheel with support load indicator |
17" shiny black alloy wheel with summer tires |
Tow bar cover |
Payload upgrade |
---|
Maximum chassis weight 1.800 kg / 1.800 kg Chassis |
Maximum chassis weight 2.000 kg / 2.000 kg Chassis incl. aluminum rims |
Cabine exterior |
---|
Entrance door with window incl. blackout blind, one-piece incl. waste garbage can |
Preparation for air conditioning incl. roof reinforcement |
Spare wheel holder in bottle holder |
Opening window bow 900 x 520 mm incl. blackout blind and insect screen |
Sliding window (kitchen) incl. blackout blind and insect screen |
Pop-up roof |
Winterisolation for pop-up roof |
Roof air conditioning (cooling and heating) |
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
Cabine interior |
---|
Shower curtain |
Wooden shower inlay |
Premium mattress 130mm incl. slatted base frame |
3-seater bunk bed (load capacity 80 kg), each with its own window |
Insect screen door in superstructure door |
Pad Style Fenit |
Water supply |
---|
Holding tank 25 ltr. with wheels |
Therme for hot water supply 5 l (hot water mixer tap included) |
Display for freshwater tank |
Level sensor for fresh and waste water tank |
Multimedia |
---|
TV preparation (1x12V socket, 2x antenna cable SAT/TV) |
LMC Home |
Gas/Electricity supply |
---|
LED ambience lightning |
LED awning lighting |
DuoControl with crash sensor |
Gas level sensor |
12 V main switch |
Battery 95 AH AGM |
Gas detector |
Exterior socket 230 V / 12 V / TV and gas |
2x USB socket for power rail |
Heating |
---|
Electrical floor heating 230 V |
Electric auxiliary heater 2 kW |
Air circulation system for gas heating |
Package elements |
---|
Gas level sensor |
Wooden shower inlay |
Shower basin |
LED ambience lightning |
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
LED awning lighting |
Level sensor for fresh and waste water tank |
LMC Home |
Shower curtain |
Shower fitting |
Tire pressure sensors |
Support wheel with support load sensor |
12 V main switch |
Voltage indicator for battery |
Accu |
Battery 95 AH AGM |
Exterior socket 230 V / 12 V / TV and gas |
Air circulation system for gas heating |
12 V ventilation system |
DuoControl with crash sensor |
Packages |
---|
LMC Home sensor package |
Style package |
Shower package |
Autarchy package hot-air heating |
Wasserversorgung |
---|
Shower basin |
Shower curtain |
Shower fitting |
Holding tank 25 ltr. with wheels |
Display for freshwater tank |
Pop-up roof |
---|
Pop-up roof |
Winterisolation for pop-up roof |
Andere Außenausstattungen |
---|
Spare wheel holder in bottle holder |
Roof air conditioning (cooling and heating) |
Preparation for air conditioning incl. roof reinforcement |
Elektro- und Gasversorgung |
---|
Voltage indicator for battery |
Accu |
Battery 95 AH AGM |
Gas detector |
Exterior socket 230 V / 12 V / TV and gas |
2x USB socket for power rail |
12 V main switch |
DuoControl with crash sensor |
Fahrzeugausstattung |
---|
Stability supports incl. plate feet |
Mover single axle (only in connection with autarchy package) |
Anti-skid system |
Support wheel with support load indicator |
Fenster & Türen |
---|
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
Entrance door with window incl. blackout blind, one-piece incl. waste garbage can |
Opening window bow 900 x 520 mm incl. blackout blind and insect screen |
Sliding window (kitchen) incl. blackout blind and insect screen |
Heating |
---|
Electrical floor heating 230 V |
Therme for hot water supply 5 l (hot water mixer tap included) |
Electric auxiliary heater 2 kW |
12 V ventilation system |
Air circulation system for gas heating |
Weitere Innenausstattungen |
---|
Premium mattress 130mm incl. slatted base frame |
3-seater bunk bed (load capacity 80 kg), each with its own window |
LED ambience lightning |
Insect screen door in superstructure door |
Multimedia |
---|
TV preparation (1x12V socket, 2x antenna cable SAT/TV) |
Payload upgrade |
---|
Maximum chassis weight 2.000 kg / 2.000 kg Chassis incl. aluminum rims |
Maximum chassis weight 1.800 kg / 1.800 kg Chassis |
a) All prices are recommended retail prices in EUR, based on the German retail prices. Prices in other countries may differ due to currency, country specific VAT, country specification, transportation charges or import duties. Your local dealer informes you about the applicable prices, taxes and duties for your country.
*The technically permissible total mass is a value specified by the manufacturer, which the vehicle must not exceed, even when loaded. It therefore has an influence on the permissible number of seats, options for selecting special equipment and remaining payload options.
Detailed information on weights and vehicle configuration can be found in our technical data, legal information section and in the configurator.
Description | Value |
---|---|
Pricea) | 26500 |
Total length | 758 |
Exterior length | 624 |
Interior length | 560 |
Total width | 233 |
Interior roof height max. | 208 |
Total height | 271 |
Weight in drivable condition (with standard equipment)* | 1333 (1266 - 1400)* |
Manufacturer-specified dimensions for optional equipment* | 122 |
Maximum permissible total weight* | 1600 |
Floor, wall, roof thickness | 40 / 30 / 30 |
Awning size | 1040 |
Berths standard / max. | 7 / 7 (○) |
Front | 205 - 200 x 76 - 74 / 177 x 78 |
Rear | 212 x 170 - 159 / 200 x 144 |
Chassis |
---|
Premium-Chassis |
Stability support |
Diagonal swing axle |
Steel rim incl. wheel hub cap with summer tires |
Anti-sway coupling |
Breakdown kit |
Wheel shock absorbers |
Cabine exterior |
---|
hinged window incl. blackout blind and insect screen |
Rear hinged window 1,450 x 520 mm incl. blackout blind and insect screen |
Service flap 1,675 x 885 mm Passenger side |
Service flap 750 x 300 mm rear passenger side |
Third breaking light |
Sidewall hammer finish sheet |
Roof hood clear glass 400 x 400 mm (sleeping) incl. blackout blind and insect screen |
Automotive tail light |
Bottle crate lid with gas strut |
Roof hood 280 x 280 mm (bathroom) incl. blackout blind and insect screen |
Roof hood clear glass 400 x 400 mm (living area) incl. blackout blind and insect screen |
Cabine interior |
---|
Drop-down bed above seating group with 80 mm cold foam mattress incl. slatted frame (load capacity 200 kg) |
Cold foam mattress 80mm in bunk beds incl. slatted frame |
Gas pressure regulators on the slatted frames of the fixed beds |
Cold foam mattress 110mm in single and double beds incl. slatted frame |
Bunk beds (load capacity 80 kg) each with its own window |
Furniture construction and ventilated upholstery and mattresses for optimum air circulation |
Storage cupboard |
Coat hooks |
Pad Style Dunit |
Vanity unit with door |
Mirror in the bathroom |
Kitchen |
---|
Three-burner hob with integrated sink split and glass cover |
Drawer with cutlery application |
Drawers with self retraction and softclose |
Compressor refrigerator 131.5 l with ice compartment |
Water supply |
---|
Central waste water drainage |
Cassette toilet |
Modern bathroom sink |
Freshwater tank with filler pipe, 44 ltr. |
Multimedia |
---|
LMC Home ready |
Gas/Electricity supply |
---|
LED interior lighting |
400 W transformer |
CEE external connection for 230 V with RCD and charger |
Reading lights |
Smoke alarm |
Power input sidewall |
Gas bottle box (for 2 x 11 kg) |
Gas regulator 30 mbar with gas hose (with country-specific adapter) |
Heating |
---|
Gas heating 3 kW |
Long Life Technology |
---|
Underbody with high-performance XPS foam and GRP |
Roof and front / rear section in GRP |
12-years-tightness-warranty |
Package elements |
---|
Wheel shock absorbers |
Anti-sway coupling |
Freshwater tank with filler pipe, 44 ltr. |
Wasserversorgung |
---|
Freshwater tank with filler pipe, 44 ltr. |
Andere Außenausstattungen |
---|
Service flap 750 x 300 mm rear passenger side |
Service flap 1,675 x 885 mm Passenger side |
Fahrzeugausstattung |
---|
Wheel shock absorbers |
Anti-sway coupling |
Fenster & Türen |
---|
Rear hinged window 1,450 x 520 mm incl. blackout blind and insect screen |
Chassis |
---|
Stability supports incl. plate feet |
Shiny black alloy wheels with summer tires |
Anti-skid system |
Mover single axle (only in connection with autarchy package) |
Support wheel with support load indicator |
17" shiny black alloy wheel with summer tires |
Tow bar cover |
Payload upgrade |
---|
Maximum chassis weight 1.800 kg / 1.800 kg Chassis |
Maximum chassis weight 2.000 kg / 2.000 kg Chassis incl. aluminum rims |
Cabine exterior |
---|
Entrance door with window incl. blackout blind, one-piece incl. waste garbage can |
Preparation for air conditioning incl. roof reinforcement |
Spare wheel holder in bottle holder |
Hinged bathroom window (frosted glass) incl. blackout blind and insect screen |
Sliding window (kitchen) incl. blackout blind and insect screen |
Roof air conditioning (cooling and heating) |
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
Cabine interior |
---|
Shower curtain |
Wooden shower inlay |
Premium mattress 130mm incl. slatted base frame |
Insect screen door in superstructure door |
Pad Style Fenit |
Water supply |
---|
Holding tank 25 ltr. with wheels |
Therme for hot water supply 5 l (hot water mixer tap included) |
Display for freshwater tank |
Level sensor for fresh and waste water tank |
Multimedia |
---|
TV preparation (1x12V socket, 2x antenna cable SAT/TV) |
LMC Home |
Gas/Electricity supply |
---|
LED ambience lightning |
LED awning lighting |
DuoControl with crash sensor |
Gas level sensor |
12 V main switch |
Battery 95 AH AGM |
Gas detector |
Exterior socket 230 V / 12 V / TV and gas |
2x USB socket for power rail |
Heating |
---|
Electrical floor heating 230 V |
Electric auxiliary heater 2 kW |
Air circulation system for gas heating |
Package elements |
---|
Gas level sensor |
Wooden shower inlay |
Shower basin |
LED ambience lightning |
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
LED awning lighting |
Level sensor for fresh and waste water tank |
LMC Home |
Shower curtain |
Shower fitting |
Tire pressure sensors |
Support wheel with support load sensor |
12 V main switch |
Voltage indicator for battery |
Accu |
Battery 95 AH AGM |
Exterior socket 230 V / 12 V / TV and gas |
Air circulation system for gas heating |
12 V ventilation system |
DuoControl with crash sensor |
Packages |
---|
LMC Home sensor package |
Style package |
Shower package |
Autarchy package hot-air heating |
Wasserversorgung |
---|
Shower basin |
Shower curtain |
Shower fitting |
Holding tank 25 ltr. with wheels |
Display for freshwater tank |
Andere Außenausstattungen |
---|
Spare wheel holder in bottle holder |
Roof air conditioning (cooling and heating) |
Preparation for air conditioning incl. roof reinforcement |
Elektro- und Gasversorgung |
---|
Voltage indicator for battery |
Accu |
Battery 95 AH AGM |
Gas detector |
Exterior socket 230 V / 12 V / TV and gas |
2x USB socket for power rail |
12 V main switch |
DuoControl with crash sensor |
Fahrzeugausstattung |
---|
Stability supports incl. plate feet |
Mover single axle (only in connection with autarchy package) |
Anti-skid system |
Support wheel with support load indicator |
Fenster & Türen |
---|
Roof hood clear glass 960x650mm with canopy and lighting above the seating area incl. blackout blind and insect screen |
Entrance door with window incl. blackout blind, one-piece incl. waste garbage can |
Hinged bathroom window (frosted glass) incl. blackout blind and insect screen |
Sliding window (kitchen) incl. blackout blind and insect screen |
Heating |
---|
Electrical floor heating 230 V |
Therme for hot water supply 5 l (hot water mixer tap included) |
Electric auxiliary heater 2 kW |
12 V ventilation system |
Air circulation system for gas heating |
Weitere Innenausstattungen |
---|
Premium mattress 130mm incl. slatted base frame |
LED ambience lightning |
Insect screen door in superstructure door |
Multimedia |
---|
TV preparation (1x12V socket, 2x antenna cable SAT/TV) |
Payload upgrade |
---|
Maximum chassis weight 2.000 kg / 2.000 kg Chassis incl. aluminum rims |
Maximum chassis weight 1.800 kg / 1.800 kg Chassis |
a) All prices are recommended retail prices in EUR, based on the German retail prices. Prices in other countries may differ due to currency, country specific VAT, country specification, transportation charges or import duties. Your local dealer informes you about the applicable prices, taxes and duties for your country.
*The technically permissible total mass is a value specified by the manufacturer, which the vehicle must not exceed, even when loaded. It therefore has an influence on the permissible number of seats, options for selecting special equipment and remaining payload options.
Detailed information on weights and vehicle configuration can be found in our technical data, legal information section and in the configurator.
€3,250.00
€590.00
a) All prices are recommended retail prices in EUR, based on the German retail prices. Prices in other countries may differ due to currency, country specific VAT, country specification, transportation charges or import duties. Your local dealer informes you about the applicable prices, taxes and duties for your country.
