LMC Tourer Alcove
The family motorhome for beautiful journeys
Sophisticated lightweight construction, six approved seats, and a striking alcove shape: the Tourer A 690 G combines family-friendly space with clever weight distribution – while remaining below the 3.5-ton limit.
The LMC Tourer Alcove impresses with its outstanding price-performance ratio. Look forward to the extensive standard equipment that guarantees you relaxation all year round!
a) All prices are recommended retail prices in EUR, based on the German retail prices. Prices in other countries may differ due to currency, country specific VAT, country specification, transportation charges or import duties. Your local dealer informes you about the applicable prices, taxes and duties for your country.
*The technically permissible total mass is a value specified by the manufacturer, which the vehicle must not exceed, even when loaded. It therefore has an influence on the permissible number of seats, options for selecting special equipment and remaining payload options.
Detailed information on weights and vehicle configuration can be found in our technical data, legal information section and in the configurator.
When buying a motorhome, camper van or urban vehicle (hereafter: motorhome), it is particularly important to choose the right layout and an appealing design. In addition, weight also plays an essential role. Family, friends, optional equipment, accessories and baggage – space must be available for all of these. At the same time, there are legal and technical limits to the configuration and load. Every motorhome is designed for a certain weight, which may not be exceeded during driving. For motorhome buyers, this raises the question: How should I configure my vehicle to accommodate passengers, baggage and accessories according to my needs without the vehicle exceeding this maximum weight? In order to make this decision easier for you, we provide you below with a few tips that are particularly important when selecting your vehicle from our portfolio:
| Description | Value |
|---|---|
| Pricea) | 68000 |
| Chassis | Fiat Ducato |
| Total length | 699 |
| Total width | 232 |
| Interior roof height max. | 208 |
| Total height | 305 |
| Wheelbase | 4035 |
| Licensed seat no. (driver included)* | 6 |
| Weight in drivable condition (with standard equipment)* | 2841 (2699 - 2983)* |
| Manufacturer-specified dimensions for optional equipment* | 148 |
| Maximum permissible total weight* | 3500 |
| Floor, wall, roof thickness | 40 / 30 / 30 |
| Berths standard / max. | 6 |
| Front | 213 x 140 |
| Middle | 184 x 143 |
| Rear | 208 x 143 - 120 |
| Chassis & Cockpit |
|---|
| Cruise control |
| Rear view camera in third brake light |
| Cab darkening |
| Third brake light |
| Traction Control |
| Passenger airbag |
| Fuel tank 90 l diesel |
| Manual air conditioning (cab) |
| Board computer |
| ABS + ESP |
| Height-adjustable driver and passenger seat |
| Seat base cover drivers cab |
| Rotable driver and passenger seat |
| Cup holder |
| Side mirrow extended |
| Lane widening 198 cm instead of 179 cm |
| Diesel particulate filter |
| Driver airbag |
| Electrically adjustable windows |
| Armrests for driver and passenger seat |
| 15” steel rim with all-weather tires incl. wheel trims |
| Power steering |
| Height-adjustable steering wheel |
| Headlights halogen |
| Comfort steeble cap covers |
| Anti-Theft device |
| Ad Blue tank 19 ltr. |
| Central locking Fiat |
| Engine variation |
|---|
| Fiat 88 kW (120 bhp) - EURO 6 E switch incl. Start & Stop function and booster |
| Cabine exterior |
|---|
| Roof hood clear glass 400 x 400 mm (kitchen, bedroom) incl. blackout blind and insect screen |
| Roof hood clear glass 400x400mm incl. blackout blind and insect screen in the bathroom |
| Lowered chassis extension for increased payload of 250 kg |
| Rear garage door, passenger side |
| Awning light on body door |
| Preparation climate, solar including roof enhancement |
| Cabine interior |
|---|
| Folding clothes rail in the toilet/shower room |
| Wood decor Taupe |
| Upholstery Rhyolith |
| Cold foam mattresses 100mm in fixed beds incl. slatted frames |
| Closet interior lighting |
| Upholstery fabric made from 100% recycled PET including Easyclean function |
| Lap belts for 5 & 6 seats |
| Expandable table top |
| Furniture construction and ventilated upholstery and mattresses for optimum air circulation |
| Lashing rails with eyelets in rear garage |
| Lowerable table base |
| Headrests in middle seat group |
| Kitchen |
|---|
| 2-burner gas hob with piezo ignition, sink and split glass cover |
| Compressor fridge 132 l with ice compartment |
| Drawer with cutlery tray |
| Drawers with softclose |
| Water supply |
|---|
| Cassette toilet |
| Warm water mixer tap |
| Water tank 100 l with filler neck, waste water tank 90 l |
| Modern bathroom sink |
| High performance tandem submersible pump |
| Multimedia |
|---|
| Radio preparation including speakers and active antenna DAB-compatible |
| Gas/Electricity supply |
|---|
| 230V socket and lighting in the rear garage |
| USB ports in lightspots |
| Gas bottle box (for 1 x 5 kg) |
| Smoke alarm |
| Gas regulator 30 mbar with gas hose (with country-specific adapter) |
| LED interior lighting |
| Multifunctional panel |
| Outer door gas box |
| Power input sidewall |
| High-performance, maintenance-free leisure battery (95 Ah AGM) |
| Electric charger for leisure and vehicle battery 12 V / 18 A |
| CEE external connection for 230 V with RCD and charger |
| Heating |
|---|
| Diesel heater 4 kW circulating air with 10 l boiler and manual control panel |
| Long Life Technologie |
|---|
| GRP side walls |
| 12-years-tightness-warranty |
| Roof and front / rear section in GRP |
| Underbody made of high-performance XPS foam and GRP |
| Cockpit |
|---|
| Traction Control |
| Cruise control |
| Fahrzeugausstattung |
|---|
| Passenger airbag |
| Rear view camera in third brake light |
| Heating |
|---|
| Diesel heater 4 kW circulating air with 10 l boiler and manual control panel |
| Weitere Innenausstattungen |
|---|
| Folding clothes rail in the toilet/shower room |
| Headrests in middle seat group |
| Chassis & Cockpit |
|---|
| Steering wheel and gear shift in leather model |
| 16" aluminum rims black with all-weather tires |
| Fog lamp in front spoiler |
| Cab darkening (pleated blinds) |
| Skid Plate polished black |
| Electrical confirmed parking brake |
| Traffic sign recognition |
| Rain and light sensor |
| Dashboard with applications (Techno Trim) |
| Bumpers painted in body color |
| Daytime running light LED |
| Engine variation |
|---|
| Fiat 103kW (140 bhp) switch - EURO 6E incl. Start & Stop function and booster |
| Fiat 103 kW (140 bhp) automatic - EURO 6E incl. Start & Stop function and booster |
| Fiat 132kW (180 bhp) Maxi Automatic - EURO 6E incl. Start & Stop function and Booster |
| Fiat 132kW (180 bhp) automatic - EURO 6E incl. Start & Stop function and booster |
| Payload upgrade |
|---|
| Increase in max. permitted mass 3,65 t / 4,25 t (depending on the chassis) |
| Cabine exterior |
|---|
| Bicycle holder for 4 bikes |
| Clear glass roof hood 700x500mm incl. blackout blind and insect screen above the seating area |
| Framed window incl. blackout blind and insect screen |
| Additional rear garage door driver‘s side |
| Matt black awning 4.5 x 2.50 m incl. LED strips |
| Opening window alcove passenger side incl. blackout blind and insect screen |
| Body door 58 cm with waste bin, window, blackout blind and central locking incl. low coupe entrance |
| Cabine interior |
|---|
| Isofix for 2 seats |
| Insect screen door |
| Water supply |
|---|
| Waste water tank insulated and automatically heated |
| Multimedia |
|---|
| 9'' display with radio, DAB+ and navigation software |
| Packages |
|---|
| Tourer A Basis Paket |
| Tourer A Exklusiv Paket |
| Fiat safety package 2 |
| Chassis Design Package Tourer Fiat |
| Package elements |
|---|
| Clear glass roof hood 700x500mm incl. blackout blind and insect screen above the seating area |
| Additional rear garage door driver‘s side |
| Driver fatigue detection |
| Lane keeping warning |
| Emergency brake assist with pedestrian detection |
| Payload upgrade |
|---|
| Increase in max. permitted mass 3,65 t / 4,25 t (depending on the chassis) |
| Cockpit |
|---|
| Bumpers painted in body color |
| Electrical confirmed parking brake |
| Traffic sign recognition |
| Lane keeping warning |
| Driver fatigue detection |
| Fahrzeugausstattung |
|---|
| Steering wheel and gear shift in leather model |
| Skid Plate polished black |
| Dashboard with applications (Techno Trim) |
| Rain and light sensor |
| Daytime running light LED |
| Emergency brake assist with pedestrian detection |
| Cab darkening (pleated blinds) |
| Fenster & Türen |
|---|
| Additional rear garage door driver‘s side |
| Framed window incl. blackout blind and insect screen |
| Clear glass roof hood 700x500mm incl. blackout blind and insect screen above the seating area |
| Weitere Innenausstattungen |
|---|
| Isofix for 2 seats |
| Awnings & bicycle holder |
|---|
| Matt black awning 4.5 x 2.50 m incl. LED strips |
| Bicycle holder for 4 bikes |
| Multimedia |
|---|
| 9'' display with radio, DAB+ and navigation software |
| Wasserversorgung |
|---|
| Waste water tank insulated and automatically heated |
a) All prices are recommended retail prices in EUR, based on the German retail prices. Prices in other countries may differ due to currency, country specific VAT, country specification, transportation charges or import duties. Your local dealer informes you about the applicable prices, taxes and duties for your country.
*The technically permissible total mass is a value specified by the manufacturer, which the vehicle must not exceed, even when loaded. It therefore has an influence on the permissible number of seats, options for selecting special equipment and remaining payload options.
Detailed information on weights and vehicle configuration can be found in our technical data, legal information section and in the configurator.
VIP sleeping area
Those who sleep here have a view of the entire motorhome. The alcove structure in the LMC A 690 offers you a comfortable sleeping area measuring 213 x 140 cm.
The word alcove comes from French (“alcôve”) and means “bed niche.” This characteristic sleeping niche gives the alcove motorhome its striking silhouette.
6-person approval under 3.5 t
Thanks to its lightweight construction, the Tourer alcove allows for comfortable vacation trips with up to 6 people. With a gross vehicle weight of less than 3.5 t, the motorhome can be driven with a class B driver's license, which makes LMC alcoves particularly attractive.
Standard diesel heating
The standard diesel heating makes the LMC Tourer Alkoven suitable for winter use, making it exciting for anyone who doesn't want to miss out on a vacation in winter.
Sustainable upholstery
The LMC Tourer Alkoven is perfect for a fun vacation with friends. The vehicle has six standard seats and sleeping places. High-quality upholstery fabrics made from 100% recycled PET with an easy-clean function complement the simple interior design.
High payload capacity
The spacious rear garage in the LMC Tourer Alkoven offers you a payload capacity of up to 250 kg and, thanks to the lashing rails, ensures that your load is securely fastened.
Compressor refrigerator
End the day in your motorhome in a relaxed atmosphere with a meal together. The compressor refrigerator in the alcove has a capacity of 132 l and guarantees reliable freshness even at high temperatures. The 2-burner gas stove with piezo ignition completes the kitchen equipment.
€3,690.00
€3,440.00
a) All prices are recommended retail prices in EUR, based on the German retail prices. Prices in other countries may differ due to currency, country specific VAT, country specification, transportation charges or import duties. Your local dealer informes you about the applicable prices, taxes and duties for your country.
Happy children mean a happy vacation! Create unforgettable memories on the road. With the LMC Tourer alcove, you always travel safely thanks to its robust GRP body, which includes side walls, floor, roof and rear wall.
The practical storage area in the rear of the Tourer alcove combines open storage compartments with closed cupboards. So there's a place for every vacation essential.
